Tune Features
- Adjusts riding modes 1 and 2
- Designed for Yamaha MT-09s with full-system aftermarket exhausts
- Tuned using the stock air filter - aftermarket filters can be used without the need for reflash
- Provides horsepower improvement across the rev range
- Slight increase above 5,000 RPM
- 1.5% increase in mid-range
- 2.5% increase to peak horsepower at 10,000 RPM
- Provides torque improvements across the rev range
- Consistent 1-2% torque increase from low range RPM to 10,000 RPM
- 1.5% increase to peak torque at 7,000 RPM
- 8.5% increase in torque at top end of rev range
- Optimizes fueling
- Rider Mode 1 receives advanced ignition timing to improve power at the top end
- Rider Mode 1 Electronic Control Valve is unrestricted at the top end and opened further above 6,000 RPM and above 20% Throttle Position Sensor
- Rider Mode 2 Electronic Control Valve opened further for optimized performance
- Lowers temperature requirement for fan activation
- Disables top speed limiter
- Disables closed loop
- Disables deceleration fuel cut
- Disables front wheel speed fault code
- Disables EVAP
This ECU reflash was tuned using premium 91 octane pump gasoline. 91 octane should always be used when operating with this tune.
Description
We've done a lot of development work on the Yamaha MT-09 and MT-09 SP, but for the most part, we focused on improving the looks...until now. We passed our Yamaha MT-09 over to our WORX Racing Division engineer team to let them unleash their racing and tuning knowledge on the Yamaha CP3. Their engineering and tuning efforts have led our TST Race Team to multiple ASRA National Championships, and have proven that the Yamaha MT-09 can be even more fun with the right tune! By optimizing the ECU with our TST Performance Reflash, you will immediately notice more power output and better performance every time you open the throttle. Not only are peak power figures increased, but we improved horsepower and torque across the entire rev range as well as optimized the MT-09 by adjusting or disabling a wide range of parameters that aid in overall performance and operational improvement. Give your Yamaha MT-09 or MT-09 SP an extra kick of power with the TST WORX Performance Tune.
AFTER TUNE: Please be aware that the Check Engine Light will be on and you will be unable to access the menu after reinstalling your flashed ECU. This issue will clear after two ride cycles of at least 35-45 MPH.
This tune was specifically designed to work with aftermarket full system exhaust and the stock air filter, although aftermarket air filters can be used without negative performance effects.
NORTH AMERICAN MARKET ONLY: Please keep in mind that this is only available for North American market Yamaha MT-09 / MT-09 SP motorcycles ONLY. All orders placed outside of the North American region will be canceled.
Q: Do I ship my ECU to you? A: Yes, it is your responsibility to ship an undamaged stock Yamaha MT-09 / MT-09 SP stock ECU to our facility in Florida for tuning. The ECU must be properly packed and free of any damage or contaminants to be tuned properly.
Q: Why is this tuned for full system exhausts? A: We wanted to achieve the best performance gains possible with by optimizing the most common performance upgrade done to the Yamaha CP3 motor while retaining the reliability it's known for.
Q: Do I pay for shipping if I am sending you my ECU? A: Yes - it is your responsibility to properly package your ECU and send it to our facility in Florida.
Q: Where do I ship my ECU? A: 623 Pleasant Street, Lake Helen FL, 32744 - Please include your order number.
Q: I'm located outside of the United States. Will I have to pay duties on this item? A: Some countries charge additional fees when a package is imported and delivered to the recipient. We have no way of knowing or estimating what these fees will be. It is the buyer's responsibility to cover these additional costs.
Q: What is your return and warranty policy? A: Returns are not accepted for this item. Please read over our policies thoroughly on our terms and conditions page BEFORE making your purchase.
